Chennai Metro Phase 2 Reaches Critical Milestone with 100% Piling and U-Girder Casting on OMR Corridor 3

Chennai Metro Rail Limited (CMRL) has announced the successful completion of two foundational engineering phases for Corridor-3 (Madhavaram – SIPCOT). The project has officially finalized all piling works and U-girder casting for the Old Mahabalipuram Road (OMR) stretch, removing significant structural hurdles for the Phase-2 expansion.

The OMR corridor is one of the most challenging segments of the network due to high traffic density and complex geological conditions. By completing these stages, CMRL is moving closer to operationalizing a transit system designed to alleviate congestion in Chennai's primary IT and business hub.

Structural Breakthroughs on the OMR Stretch

The completion of piling works represents a massive logistical feat. A total of 3,066 piles have been installed between Nehru Nagar and Sholinganallur. This phase required navigating live traffic and varying soil compositions.

Production efficiency peaked in October 2023, when the project team successfully installed 185 piles in a single month. This acceleration was necessary to keep the project on track despite the inherent difficulties of working in a high-traffic urban environment.

Simultaneously, the project has finalized the casting of all 582 precast prestressed U-Girders. These components are essential for the elevated sections of the track and station supports. The production was managed through a dedicated 35-acre casting yard located at Semmancheri.

The casting process reached its highest output in December 2024, with 40 girders produced in that month alone. The final girder was marked with a ceremonial concrete pour, signaling the end of the casting phase for this corridor.

Overcoming Engineering and Geological Hurdles

The construction of Corridor-3 required highly specialized planning to avoid paralyzing the city's movement. CMRL implemented stage-wise construction to maintain traffic flow at critical intersections, most notably at Thoraipakkam and Sholinganallur.

In these areas, the metro stations are being integrated with existing TNRDC flyovers, requiring precise engineering to ensure structural integrity without disrupting existing road infrastructure.

Geological challenges were particularly acute at Sholinganallur, where teams encountered hard rock strata. To overcome this, CMRL deployed specialized drilling equipment and optimized boring methods to ensure the piles reached the required depth and stability.

Corridor 3 Technical Specifications

The following data outlines the scale of the achievements on the OMR stretch of Corridor-3:

Component	Total Quantity	Key Milestone/Peak Detail	Location/Facility
Piling Works	3,066 Piles	185 piles installed (Oct 2023)	Nehru Nagar to Sholinganallur
U-Girders	582 Units	40 girders cast (Dec 2024)	Semmancheri Casting Yard
Girder Types	2 Variations	30m viaduct & 17.5m station	OMR Corridor 3
Casting Yard Size	35 Acres	Full capacity production	Semmancheri

Implications for Urban Mobility

The completion of these structural elements shifts the project from the "foundation" phase to the "superstructure" phase. For commuters and businesses along the OMR, this means the project is moving toward timely delivery, which will eventually provide a sustainable alternative to the current road-based congestion.

By integrating the metro with existing flyovers and utilizing precast components, CMRL is reducing the time required for on-site assembly, which should minimize future disruptions for residents and daily commuters.

The successful navigation of the OMR's geological and traffic challenges sets a benchmark for future phases of Chennai's transit expansion.

---

---
